MG RX-75 Gun Tank English Manual & Color Guide

Bandai Master Grade RX-75 Gun Tank Translated English Construction Manual

Ryu Jose and Hayato Kobayashi's RX-75 Gun Tank from the original Mobile Suit Gundam Anime series. I already wrote up my thoughts with regards to the Gun Tank on this older post, kindly check it out least I sound like a parrot that keeps on repeating itself *snicker*.

The Master Grade RX-75 Gun Tank is selling for 4800 yen at Hobby Link Japan, 3520 yen at Amiami, 3360 yen at HWJapan.

Color Guide DescriptionPaint Ratios
MG Guntank head part etcWhite (H1)(100%) + Light Brown (H321)(small dose)
MG Guntank main body etcBlue (H5)(45%) + White (H1)(25%) + Red (H3)(15%) + Black (H2)(15%)
MG Guntank intake etcYellow (H4)(60%) + White (H1)(30%) + Orange (H14)(10%)
MG Guntank abdomen etcMonza Red/Red Madder (H86)(100%)
MG Guntank arms etcNeutral Gray (H53)(70%) + White (H1)(20%) + Khaki Green (H80)(5%) + Wood Brown (H37)(5%) +
MG Guntank crawler etcNeutral Gray (H53)(70%) + Black (H2)(15%) + Medium Blue/Intermediate Blue (H56)(15%)
MG Guntank core fighter blue partBright Blue/Indy Blue (H15)(45%) + White (H1)(35%) + Cobalt Blue (H35)(20%)
uniform common colors red partMonza Red/Red Madder (H86)(100%)
uniform common colors line etcYellow (H4)(45%) + White (H1)(35%) + Orange (H14)(20%)
uniform common colors feet partWhite (H1)(100%)
hayato kobayashi/ryu jose uniformBright Blue/Indy Blue (H15)(100%)
hayato kobayashi/ryu jose bootsMiddle Stone (H71)(100%)
milia yashima uniformPink (H19)(90%) + Monza Red/Red Madder (H86)(10%)
milia yashima bootsDark Earth (H72)(90%) + Mahogany (H84)(10%)
bright noa uniformWhite (H1)(90%) + Neutral Gray (H53)(10%)
bright noa bootsMiddle Stone (H71)(100%)
hayato kobayashi/ryu jose normal suits yellow partYellow (H4)(70%) + White (H1)(30%)
hayato kobayashi/ryu jose normal suits line partNeutral Gray (H53)(40%) + Violet (H49)(60%)
hayato kobayashi/ryu jose normal suits collar partBlack (H2)(100%)
hayato kobayashi/ryu jose normal suits helmet foreheadWhite (H1)(100%)
hayato kobayashi/ryu jose normal suits visorSky Blue (H25)(100%)
hayato kobayashi/ryu jose normal suits seatbeltGreen (H6)(80%) + Bright Blue/Indy Blue (H15)(20%)
